Escape hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 560 x 560.

Cut-out dimensions C x D (in mm): 500 x 500.

Cutting radius R (in mm): 32.

Escape hatches - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke” colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 552 x 552.

Cut-out dimensions C x D (in mm): 470 x 470.

Ventilation hatch - Type PLANUS (AII)

These hatches feature a satin anodized aluminum frame with a 75mm corner radius and a 10mm dark smoke acrylic cover.

A friction hinge allows the hatches to stay open at

any angle up to 180º.

The PLANUS type is suitable for design category A, zone II.

Features :

Number of handles: 1.

Shape: Square.

Panel opening: Frameless.

Friction hinges: Yes.

External dimensions A x B (in mm): 390 x 260.

Cut-out dimensions C x D (in mm): 340 x 210.

Deck hatch - The FGHF series is specially designed for new boats.

Suitable for new builds as it is necessary to provide a hatch in the deck. After installing the FGHF, the hatch is completely recessed into the deck, creating a smooth, flush appearance.

The FGHF series is distinguished by its fully flush bolts and handles. Designed larger, they are equipped with a grip in the handle so that they can be opened from the outside using a winch handle.

The FGHF (AII Device Location Area) series is available in four sizes.

Made from 12mm thick 'dark smoke' acrylic with a maintenance-free polished and anodised aluminium frame.

Features :

External dimensions A x B (in mm): 330 x 330.

Cut-out dimensions C x D (in mm): 260 x 260.

Number of handles: 1.

Material: Aluminum.

Shape: Flush.

Panel opening: Frameless.

Interior finishing frames with mosquito net.

Perfect finish and protection against insects.

The full range of panels can be supplied with a depth-adjustable trim with mosquito netting.

These white synthetic trims are designed to cover the space between the hatch and the inside face of the boat.

The frame depth can be cut to size to fit any wall thickness up to 50mm.

The integrated, hinged mosquito net can be easily removed for easy cleaning.

Fits hatches: ALTD420SL.

Wall thickness H (in mm): 44 - 72.

Set the perfect atmosphere for your cabin.

The HMB series is both a mosquito net and a roller blind.

This blind and screen combination is designed specifically for escape and ventilation deck hatches.

The sleek, push-to-focus design to maximize vision has modified hooks for durability and strong, easy-to-reach adjustable springs for manually resetting screen tension.

A blind and an automatic roller mosquito net are located on either side.

Alternatively, by pushing the handle in the opposite direction, the blind retracts and the mosquito net covers the opening.

The separation of the magnetic clasp in the handles allows the blind and mosquito net to automatically retract into their housings.

All parts of the case are made of off-white powder coated aluminum and will therefore last for years without fading.

The blind and mosquito net are made from a UV stabilized gray PVC coated material.

An easy-to-install finishing strip can be cut to size and covers deck openings up to 75mm thick.

The HMB series is designed for hatches with corner radii of 43 mm or less.

Features :

Suitable for hatches: ALT5038SL / MAG5038SL.

Set the perfect atmosphere for your cabin.

The HMB series is both a mosquito net and a roller blind.

This blind and screen combination is designed specifically for escape and ventilation deck hatches.

The sleek, push-to-focus design to maximize vision has modified hooks for durability and strong, easy-to-reach adjustable springs for manually resetting screen tension.

A blind and an automatic roller mosquito net are located on either side.

Alternatively, by pushing the handle in the opposite direction, the blind retracts and the mosquito net covers the opening.

The separation of the magnetic clasp in the handles allows the blind and mosquito net to automatically retract into their housings.

All parts of the case are made of off-white powder coated aluminum and will therefore last for years without fading.

The blind and mosquito net are made from a UV stabilized gray PVC coated material.

An easy-to-install finishing strip can be cut to size and covers deck openings up to 75mm thick.

The HMB series is designed for hatches with corner radii of 43 mm or less.

Features :

Suitable for hatches: FGH5139.
