CAPOT - TRAPPE TYPE PLANUS

Escape hatch - Type PLANUS (AII)

These hatches feature a satin anodized aluminum frame with a 75mm corner radius and a 10mm dark smoke acrylic cover.

A friction hinge allows the hatches to stay open at

any angle up to 180º.

The PLANUS type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Frameless.

Friction hinges: Yes.

External dimensions A x B (in mm): 521 x 521.

Cut-out dimensions C x D (in mm): 471 x 471.

Escape hatch - Type PLANUS (AII)

These hatches feature a satin anodized aluminum frame with a 75mm corner radius and a 10mm dark smoke acrylic cover.

A friction hinge allows the hatches to stay open at

any angle up to 180º.

The PLANUS type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Frameless.

Friction hinges: Yes.

External dimensions A x B (in mm): 474 x 474.

Cut-out dimensions C x D (in mm): 424 x 424.

Deck hatches - Type PLANUS (AII)

These hatches feature a satin anodized aluminum frame with a 75mm corner radius and a 10mm dark smoke acrylic cover.

A friction hinge allows the hatches to stay open at

any angle up to 180º.

The PLANUS type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Frameless.

Friction hinges: Yes.

External dimensions A x B (in mm): 424 x 424.

Cut-out dimensions C x D (in mm): 374 x 374.

Ventilation hatch - Type PLANUS (AII)

These hatches feature a satin anodized aluminum frame with a 75mm corner radius and a 10mm dark smoke acrylic cover.

A friction hinge allows the hatches to stay open at

any angle up to 180º.

The PLANUS type is suitable for design category A, zone II.

Features :

Number of handles: 1.

Shape: Square.

Panel opening: Frameless.

Friction hinges: Yes.

External dimensions A x B (in mm): 390 x 260.

Cut-out dimensions C x D (in mm): 340 x 210.

Deck hatches - Type PLANUS (AII)

These hatches feature a satin anodized aluminum frame with a 75mm corner radius and a 10mm dark smoke acrylic cover.

A friction hinge allows the hatches to stay open at

any angle up to 180º.

The PLANUS type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Frameless.

Friction hinges: Yes.

External dimensions A x B (in mm): 474 x 344.

Cut-out dimensions C x D (in mm): 424 x 294.

Ventilation hatch - Type PLANUS (AII)

These hatches feature a satin anodized aluminum frame with a 75mm corner radius and a 10mm dark smoke acrylic cover.

A friction hinge allows the hatches to stay open at

any angle up to 180º.

The PLANUS type is suitable for design category A, zone II.

Features :

Number of handles: 1.

Shape: Square.

Panel opening: Frameless.

Friction hinges: Yes.

External dimensions A x B (in mm): 350 x 280.

Cut-out dimensions C x D (in mm): 300 x 230.

Ventilation hatch - Type PLANUS (AII)

These hatches feature a satin anodized aluminum frame with a 75mm corner radius and a 10mm dark smoke acrylic cover.

A friction hinge allows the hatches to stay open at

any angle up to 180º.

The PLANUS type is suitable for design category A, zone II.

Features :

Number of handles: 1.

Shape: Square.

Panel opening: Frameless.

Friction hinges: Yes.

External dimensions A x B (in mm): 280 x 280.

Cut-out dimensions C x D (in mm): 230 x 230.
