Complete windshield washer kit type which includes a reservoir with integrated pump, a tube with non-return valve, a rotary switch and a unique long double spray nozzle to reach the thick frame of the windshield

An extension kit (code HDSXTB) consisting of a second dual spray nozzle, additional hose and T-fitting is available and recommended to maintain sufficient flow and pressure.

Features

Voltage (in V): 24.

Intensity (in A): 0.90.

Tube length: 3 m

Tank capacity: 1.5 liters

Pump flow rate: 0.88 liters/min.

Plastic cover for RW and DIN range motors.

By installing the plastic cover you reduce the indicated panel thickness by 3 mm.

Comes complete with base plate.

Rotating portholes - SLR type

Perfect vision in all circumstances!

The centrifugal force caused by the rotating tempered glass, which reaches its maximum revolutions per minute in 25 seconds, instantly clears the screen of rain, snow and spray.

Even dirt and salt won't cause smears.

The SLR range is available in 2 sizes and meets all EMC requirements.

Characteristic :

Cut Ø A (in mm): 275.

Ø B (in mm): 250.

Ø C (in mm): 300.

Consumption (in V): 24.

Stainless steel portholes - Type PQ (AII)

VETUS offers a range of portholes made of stainless steel (AISI 316) in categories AI and AII.

They come with a stainless steel (AISI 316) inner frame, 8mm "smoked" acrylic glazing and a mosquito net on anodized aluminum frame.

These portholes are suitable for a structure thickness of 3 to 11mm and include a counter frame.

Screws for different wall thicknesses can be

ordered separately.

Features :

External dimensions (in mm): 184.

Cut-out dimensions (in mm): 151.

Replacement mosquito net: HORPQ52.

Ultra-thin portholes - Type PW

The PW series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PW portholes are made from fashionable satin black aluminum with 10mm thick "dark smoke" tinted acrylic for a premium look.

Features :

External dimensions A Ø (in mm): 260.

Cutting dimensions B Ø (in mm): 236.

Replacement mosquito net: HOR2213.

Stainless steel portholes - Type PWS (AI)

VETUS offers a range of portholes made of stainless steel (AISI 316) in categories AI and AII.

They come with a stainless steel (AISI 316) inner frame, 8mm "smoked" acrylic glazing and a mosquito net on anodized aluminum frame.

These portholes are suitable for a structure thickness of 3 to 18mm.

Screws for different wall thicknesses can be ordered separately.

Features :

External dimensions (in mm): 220.

Cut-out dimensions (in mm): 198.

Replacement mosquito net: HOR31S.

Ultra-thin portholes - Type PL (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 646 X 191.

Cut-out dimensions C x D (in mm): 626 X 171.

Replacement mosquito net: HOR741.
