Hublot rectangulaires et ovales VETUS

Ultra-thin portholes - Type PL (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 449 X 264.

Cut-out dimensions C x D (in mm): 429 X 244.

Replacement mosquito net: HOR751.

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 399 x 199.

Cut-out dimensions C x D (in mm): 375 x 175.

Cutting radius R (in mm): 87.

Replacement mosquito net: HOR16.

Ultra-thin portholes - Type PZ (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 451 x 274.

Cut-out dimensions C x D (in mm): 427 x 250.

Cutting radius R (in mm): 54.

Replacement mosquito net: HOR67.

Ultra-thin portholes - Type PL (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 646 X 191.

Cut-out dimensions C x D (in mm): 626 X 171.

Replacement mosquito net: HOR741.

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 390 x 220.

Cut-out dimensions C x D (in mm): 366 x 196.

Cutting radius R (in mm): 98.

Replacement mosquito net: HOR15.

Replacement mosquito net for porthole type PMS24A2 and PMS24A1.

Stainless steel portholes - Type PMS (AI)

VETUS offers a range of portholes made of stainless steel (AISI 316) in categories AI and AII.

They come with a stainless steel (AISI 316) inner frame, 8mm "smoked" acrylic glazing and a mosquito net on anodized aluminum frame.

These portholes are suitable for a structure thickness of 3 to 18mm.

Screws for different wall thicknesses can be ordered separately.

Features :

External dimensions A x B (in mm): 346 x 199.

Cut-out dimensions C x D (in mm): 322 x 177.

Replacement mosquito net: HOR23S.
