RC8-8 VERTICAL COMBINED...

RC8-8 VERTICAL COMBINED CHAIN/ROPE WINDLASS - 12V CW - 1000W 165TDC 8MM CHAIN

RÉF. DM_VE_P102562 | VETUS - MAXWELL

The more powerful RC8-8 series can be used with 8mm chain spliced onto 14mm or 16mm 8-strand (braid) rope.

The ingenious Wave Design chain/rope system (chainwheel) is capable of accommodating a wide range of chain pitch differences within the specified chain size diameters. A sleek, low-profile version and a stainless steel (AISI 316) splined capstan drum version are available. The heavy-duty stainless steel (AISI 316) pressure arm is designed to effectively assist in gripping the cable/chain splice, giving the RC8 series an unmatched level of performance. In combination with a heavy-duty, large-diameter stainless steel (AISI 316) pre-loaded spring, the pressure arm always exerts maximum control pressure. Works equally effectively with chain-driven bicycles. The huge through deck hawse chute ensures easy entry and exit of the cable/chain in and out of the anchor locker. The sealed oil bath and marine grade hard anodized alloy gearbox provide maximum efficiency with a screw and worm wheel.

Simple two-piece installation saves time and money and allows for easy retrofitting without windlass disassembly. Unique spacer tube design allows installation on virtually any deck thickness and multiple mounting positions. Self-aligning gearbox ensures optimal gearbox and motor location in virtually any installation situation. Complete topworks disassembly is possible using only the supplied handle and an Allen key. A "free fall" manual override, using the emergency clutch crank/handle, is also provided.

Features :

Rope (in mm): 14-16.

Rope/Chain: Rope / chain.

Drum: No.

Motor (in W): 1000.

Weight (in kg): 8.

Maximum traction/lift (in kg): 600.

Short chain link (in mm): 8.

Chain (in mm): 6-7.

Vertical/Horizontal: Vertical.

Voltage (in V): 12.

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
1959.5 €1,959.50 VAT included
€1,632.92 VAT excluded
Quantity
Voir le produit
VERTICAL CHAIN WINDLASS...

VERTICAL CHAIN WINDLASS 1000 VWLP 150TDC 12V

RÉF. DM_VE_P100441 | VETUS - MAXWELL

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
3016 €3,016.00 VAT included
€2,513.33 VAT excluded
Quantity
Voir le produit
VERTICAL CHAIN WINDLASS...

VERTICAL CHAIN WINDLASS 1500 VWCLP 100TDC 24V CW 56:1

RÉF. DM_VE_P100430 | VETUS - MAXWELL

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
3231.5 €3,231.50 VAT included
€2,692.92 VAT excluded
Quantity
Voir le produit
