Ref. DAM : DM_VE_KSTEUN40A

K40A TYPE ENGINE MOUNT (EACH) - SHORE 50

75.5 €75.50 VAT included
€62.92 VAT excluded
On demand
K40A TYPE ENGINE MOUNT (EACH) - SHORE 50
K40A TYPE ENGINE MOUNT (EACH) - SHORE 50
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
K40A TYPE ENGINE MOUNT (EACH) - SHORE 50
K40A TYPE ENGINE MOUNT (EACH) - SHORE 50
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
75.5 €75.50 VAT included
€62.92 VAT excluded

For 3-cylinder marine diesel engines.

Type K40 has a relatively soft rubber compound that meets the requirements of 3-cylinder marine diesel engines.

The rubber elements provide optimal vibration damping. The KSTEUN type features internal buffers that limit motor movement when starting or stopping. It is also protected against overload and shear.

Stiffness ratio:

Vertical: 1

Lateral: 1

Longitudinal: 2.4

Minimum load (Static): 25Kg

Minimum Compression (Static): 5 mm

Maximum load (Static + Dynamic): 40 Kg

Maximum compression (Static + Dynamic): 8mm

Shore 50

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

For 3-cylinder marine diesel engines.

Type K40 has a relatively soft rubber compound that meets the requirements of 3-cylinder marine diesel engines.

The rubber elements provide optimal vibration damping. The KSTEUN type features internal buffers that limit motor movement when starting or stopping. It is also protected against overload and shear.

Stiffness ratio:

Vertical: 1

Lateral: 1

Longitudinal: 2.4

Minimum load (Static): 25Kg

Minimum Compression (Static): 5 mm

Maximum load (Static + Dynamic): 40 Kg

Maximum compression (Static + Dynamic): 8mm

Shore 50

  • VETUS : KSTEUN40A
  • VDM : VETKSTEUN40A
