WATERLOCK SYNTHETIC TYPE MGP, INLET 102 MM - 45 DEGREES, OUTLET 102 MM
Special waterlocks for large boats type MG.
Excellent noise reduction, minimal back pressure.
This type of water lock is designed for modern, high-performance boats with one or two large engines that have little space to spare in the engine room. The outlet connection on top can rotate 360°, and the inlet connection is angled upwards by 45°. The MG type can only be installed in water-injected exhaust systems. Its body is made entirely of synthetic materials, therefore not susceptible to corrosion or galvanic action.
Features :
• Excellent sound reduction
• Minimal back pressure
• Drain plug for winter storage
• Suitable for internal pipe diameters Ø 102 mm
• Capacities of 23 liters
• Supplied with AISI 316 stainless steel clamping bands
• M12 thread purge
• Optional temperature sensor
Technical characteristics:
• Capacity: 23 L
• Diameter d: 102 mm
• Diameter D: 102 mm
• Diameter A: 270 mm
• Diameter B: 450 mm
Pièce non en stock.
Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».
Un conseiller traitera votre demande dans la journée.
