Ref. DAM : DM_VE_MGP5455

SYNTHETIC WATERLOCK, TYPE MGP, 127 MM INLET - 45 DEGREES, 127 MM OUTLET

889.5 €889.50 VAT included
€741.25 VAT excluded
On demand
SYNTHETIC WATERLOCK, TYPE MGP, 127 MM INLET - 45 DEGREES, 127 MM OUTLET
SYNTHETIC WATERLOCK, TYPE MGP, 127 MM INLET - 45 DEGREES, 127 MM OUTLET
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
SYNTHETIC WATERLOCK, TYPE MGP, 127 MM INLET - 45 DEGREES, 127 MM OUTLET
SYNTHETIC WATERLOCK, TYPE MGP, 127 MM INLET - 45 DEGREES, 127 MM OUTLET
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
889.5 €889.50 VAT included
€741.25 VAT excluded

Special waterlocks for large boats type MG.

Excellent noise reduction, minimal back pressure.

This type of water lock is designed for modern, high-performance boats with one or two large engines that have little space to spare in the engine room. The outlet connection on top can rotate 360°, and the inlet connection is angled upwards by 45°. The MG type can only be installed in water-injected exhaust systems. Its body is made entirely of synthetic materials, therefore not susceptible to corrosion or galvanic action.

Features :

• Excellent sound reduction

• Minimal back pressure

• Drain plug for winter storage

• Suitable for internal pipe diameters Ø 102 mm

• Capacities of 23 liters

• Supplied with AISI 316 stainless steel clamping bands

• M12 thread purge

• Optional temperature sensor

Technical characteristics:

• Capacity: 23 L

• Diameter d: 127 mm

• Diameter D: 127 mm

• Diameter A: 270 mm

• Diameter B: 450 mm

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Special waterlocks for large boats type MG.

Excellent noise reduction, minimal back pressure.

This type of water lock is designed for modern, high-performance boats with one or two large engines that have little space to spare in the engine room. The outlet connection on top can rotate 360°, and the inlet connection is angled upwards by 45°. The MG type can only be installed in water-injected exhaust systems. Its body is made entirely of synthetic materials, therefore not susceptible to corrosion or galvanic action.

Features :

• Excellent sound reduction

• Minimal back pressure

• Drain plug for winter storage

• Suitable for internal pipe diameters Ø 102 mm

• Capacities of 23 liters

• Supplied with AISI 316 stainless steel clamping bands

• M12 thread purge

• Optional temperature sensor

Technical characteristics:

• Capacity: 23 L

• Diameter d: 127 mm

• Diameter D: 127 mm

• Diameter A: 270 mm

• Diameter B: 450 mm

  • VETUS : MGP5455
  • VDM : VETMGP5455
