Ref. DAM : DM_VE_MGL8458A

SYNTHETIC WATERLOCK, TYPE MGL, 203 MM INLET-45 DEGREES, 203 MM OUTLET

1170.5 €1,170.50 VAT included
€975.42 VAT excluded
On demand
SYNTHETIC WATERLOCK, TYPE MGL, 203 MM INLET-45 DEGREES, 203 MM OUTLET
SYNTHETIC WATERLOCK, TYPE MGL, 203 MM INLET-45 DEGREES, 203 MM OUTLET
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
SYNTHETIC WATERLOCK, TYPE MGL, 203 MM INLET-45 DEGREES, 203 MM OUTLET
SYNTHETIC WATERLOCK, TYPE MGL, 203 MM INLET-45 DEGREES, 203 MM OUTLET
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
1170.5 €1,170.50 VAT included
€975.42 VAT excluded

Waterlock designed for modern high performance boats with one or two large engines that have limited space in the engine room.

The outlet connection at the top can be rotated 360º and the inlet connection is at a 45º upward angle. The MG type can only be installed in water-injected exhaust systems. Its body is made entirely of synthetic materials, therefore insensitive to corrosion or galvanic action.

To optimize noise reduction, flexible supports for MG and HPW watercoks can be used.

Features :

• Excellent sound reduction

• Minimal back pressure

• Drain plug for winter storage

• Suitable for internal pipe diameters Ø 90, 102, 127, 152, 209 or 250 mm

• Capacities of 23, 75 or 130 liters

• Supplied with AISI 316 stainless steel clamping bands

• M12 thread purge

• Optional temperature sensor

Technical characteristics:

Capacity (liters): 130.

Water inlet pipe connection diameter (mm): 203.

Outlet pipe connection diameter (mm): 203.

Length (mm): 890.

Width (mm): 500.

Height (mm): 750.

Airlock position: Vertical.

% Noise Reduction: 25.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Waterlock designed for modern high performance boats with one or two large engines that have limited space in the engine room.

The outlet connection at the top can be rotated 360º and the inlet connection is at a 45º upward angle. The MG type can only be installed in water-injected exhaust systems. Its body is made entirely of synthetic materials, therefore insensitive to corrosion or galvanic action.

To optimize noise reduction, flexible supports for MG and HPW watercoks can be used.

Features :

• Excellent sound reduction

• Minimal back pressure

• Drain plug for winter storage

• Suitable for internal pipe diameters Ø 90, 102, 127, 152, 209 or 250 mm

• Capacities of 23, 75 or 130 liters

• Supplied with AISI 316 stainless steel clamping bands

• M12 thread purge

• Optional temperature sensor

Technical characteristics:

Capacity (liters): 130.

Water inlet pipe connection diameter (mm): 203.

Outlet pipe connection diameter (mm): 203.

Length (mm): 890.

Width (mm): 500.

Height (mm): 750.

Airlock position: Vertical.

% Noise Reduction: 25.

  • VETUS : MGL8458A
  • VDM : VETMGL8458A
