Ref. DAM : DM_VE_PM141

HUBLOT, ALUMINUM, CATEGORY A1 (CUT OUT 338 X 122 MM), RADIUS 61 MM

264 €264.00 VAT included
€220.00 VAT excluded
On demand
HUBLOT, ALUMINUM, CATEGORY A1 (CUT OUT 338 X 122 MM), RADIUS 61 MM
HUBLOT, ALUMINUM, CATEGORY A1 (CUT OUT 338 X 122 MM), RADIUS 61 MM
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
HUBLOT, ALUMINUM, CATEGORY A1 (CUT OUT 338 X 122 MM), RADIUS 61 MM
HUBLOT, ALUMINUM, CATEGORY A1 (CUT OUT 338 X 122 MM), RADIUS 61 MM
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
264 €264.00 VAT included
€220.00 VAT excluded

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 362 x 146.

Cut-out dimensions C x D (in mm): 338 x 122.

Cutting radius R (in mm): 61.

Replacement mosquito net: HOR14.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Ultra-thin portholes - Type PM (AI)

The PL series portholes are so flush that they resemble fritted glass and are suitable for installation in

a variety of materials.

Despite their low thickness, they are still CE approved for the AI location area, which means they can be used for all areas listed in the ISO standard! A very flat aluminum edge combined with the clamping mechanism ensures a very low-profile porthole even when mounted in the glass itself. They are also equipped with the new ergonomic buttons.

These ultra-thin portholes can accept panel thicknesses ranging from 2 to 20 mm. The inside of the clamping profile can be finished with the supplied trim. All

PL portholes are made of fashionable satin black aluminum with 10mm thick "black smoke" tinted acrylic for a premium look.

Features :

External dimensions A x B (in mm): 362 x 146.

Cut-out dimensions C x D (in mm): 338 x 122.

Cutting radius R (in mm): 61.

Replacement mosquito net: HOR14.

  • VETUS : PM141
  • VDM : VETPM141
