Ref. DAM : DM_VE_ALTD520SL

ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)

735 €735.00 VAT included
€612.50 VAT excluded
On demand
ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)
ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)
ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)
ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)
ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)
ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)
ALTUS TYPE D520 SURVIVAL HATCH, D-SHAPE (CUT OUT SIZE 518 X 450 MM)
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
735 €735.00 VAT included
€612.50 VAT excluded

Escape hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 592 x 524

Cut-out dimensions C x D (in mm): 518 x 450.

Number of handles: 2.

Mosquito net type: HCMD520.

Shape: Oval.

Friction hinges: No.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Escape hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 592 x 524

Cut-out dimensions C x D (in mm): 518 x 450.

Number of handles: 2.

Mosquito net type: HCMD520.

Shape: Oval.

Friction hinges: No.

  • VETUS : ALTD520SL
  • VDM : VETALTD520SL
