Ref. DAM : DM_VE_ALT4747SL

ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)

606.5 €606.50 VAT included
€505.42 VAT excluded
On demand
ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)
ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)
ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)
ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)
ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)
ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)
ALTUS TYPE 4747 SURVIVAL HATCH (CUT OUT SIZE 470 X 470 MM)
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
606.5 €606.50 VAT included
€505.42 VAT excluded

Escape hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 544 x 544.

Cut-out dimensions C x D (in mm): 470 x 470.

Number of handles: 2.

Mosquito net type: HCM4747.

Shape: Square.

Friction hinges: No.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Escape hatches made with a robust 21mm high aluminium profile, with an anodised frame and suitable for design category A and location zone II.

The acrylic is 10mm thick and comes in a “dark smoke” color.

These hatches come with adjusters that are stylish and easy to use, allowing the lid to be held open at almost any angle up to 90°.

The ALTUS type can be mounted on the deck and opened from

inside and outside. It has a ventilation position and can be completely waterproof.

Features :

External dimensions A x B (in mm): 544 x 544.

Cut-out dimensions C x D (in mm): 470 x 470.

Number of handles: 2.

Mosquito net type: HCM4747.

Shape: Square.

Friction hinges: No.

  • VETUS : ALT4747SL
  • VDM : VETALT4747SL
