Ref. DAM : DM_VE_VENT7624A

VENT TYPE EXTRACTOR FAN 24 V, 4 AMP. CAPACITY 4M³/MIN DIAM 76 MM

135 €135.00 VAT included
€112.50 VAT excluded
On demand
VENT TYPE EXTRACTOR FAN 24 V, 4 AMP. CAPACITY 4M³/MIN DIAM 76 MM
VENT TYPE EXTRACTOR FAN 24 V, 4 AMP. CAPACITY 4M³/MIN DIAM 76 MM
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
VENT TYPE EXTRACTOR FAN 24 V, 4 AMP. CAPACITY 4M³/MIN DIAM 76 MM
VENT TYPE EXTRACTOR FAN 24 V, 4 AMP. CAPACITY 4M³/MIN DIAM 76 MM
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
135 €135.00 VAT included
€112.50 VAT excluded

This exhaust fan is intended for the extraction of heat from the engine compartment when the engines are stopped or of gasoline vapors. Ignition protected, excluding hose, conforming to marine standard ISO 9097.

A mounting bracket is provided.

Technical characteristics:

Voltage (V): 24.

Pipe diameter in mm: 76.

Capacity (m³/minute): 4.

Free passage area (cm2): 76.

A (in mm): 186.

B (in mm): 168.

C (in mm): 88.

D (in mm): 157.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

This exhaust fan is intended for the extraction of heat from the engine compartment when the engines are stopped or of gasoline vapors. Ignition protected, excluding hose, conforming to marine standard ISO 9097.

A mounting bracket is provided.

Technical characteristics:

Voltage (V): 24.

Pipe diameter in mm: 76.

Capacity (m³/minute): 4.

Free passage area (cm2): 76.

A (in mm): 186.

B (in mm): 168.

C (in mm): 88.

D (in mm): 157.

  • VETUS : VENT7624A
  • VDM : VETVENT7624A
