Ref. DAM : DM_V _SAELATY10022

22MM CLAMP COUPLING CAKE

€0.00 VAT included

€0.00 VAT excluded

On demand

22MM CLAMP COUPLING CAKE

22MM CLAMP COUPLING CAKE

22MM CLAMP COUPLING CAKE

22MM CLAMP COUPLING CAKE

keyboard_arrow_left

keyboard_arrow_right

22MM CLAMP COUPLING CAKE

22MM CLAMP COUPLING CAKE

22MM CLAMP COUPLING CAKE

22MM CLAMP COUPLING CAKE

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand

€0.00 VAT included

€0.00 VAT excluded

COUPLING CAKE 22MM

Electro-cadmium-plated steel clamp coupling with grub screw and keyway. 4 holes.

Shaft diameter: 22mm

Exterior: 100mm

Centering diameter: 50 female

Number of holes: 4 x 10.5mm

Center distance: 78mm

Shaft length: 88-96mm

Yanmar 1GM - 2GM - 3GM - YS8 - YS12 - KM2P inverter assembly

Read the detailed description

Quantity

Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit

Full description

COUPLING CAKE 22MM

Electro-cadmium-plated steel clamp coupling with grub screw and keyway. 4 holes.

Shaft diameter: 22mm

Exterior: 100mm

Centering diameter: 50 female

Number of holes: 4 x 10.5mm

Center distance: 78mm

Shaft length: 88-96mm

Yanmar 1GM - 2GM - 3GM - YS8 - YS12 - KM2P inverter assembly

YANMAR : 58070122000
VDM : SAELATY10022
VDM : SAE-LATY10022

Un doute ? > contact us
