Ref. DAM : DM_VE_WTANK40C

SYNTHETIC DRINKING WATER TANK, 40 L, FITTINGS INCLUDED

319.5 €319.50 VAT included
€266.25 VAT excluded
On demand
SYNTHETIC DRINKING WATER TANK, 40 L, FITTINGS INCLUDED
SYNTHETIC DRINKING WATER TANK, 40 L, FITTINGS INCLUDED
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
SYNTHETIC DRINKING WATER TANK, 40 L, FITTINGS INCLUDED
SYNTHETIC DRINKING WATER TANK, 40 L, FITTINGS INCLUDED
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
319.5 €319.50 VAT included
€266.25 VAT excluded

Base tank with easy-to-screw inspection cover, made of very high-quality synthetic materials and

identical to those of rigid tanks. The wall thickness is 7mm.

Supplied with all necessary fittings, saving considerable installation time. Fixed hose connector Ø 38 mm for filling and fixed hose connector Ø 16 mm for venting. Rotating hose connector Ø 13 mm with pick-up hose for water suction.

A center point for an SAE flange pressure gauge transmitter is integrated into the casting, along with five blind bolt holes.

Features :

Tank volume (liter): 40.

Ø Filling (mm): 38.

Ø Suction (mm): 16.

Ø Vent (mm): 13.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Base tank with easy-to-screw inspection cover, made of very high-quality synthetic materials and

identical to those of rigid tanks. The wall thickness is 7mm.

Supplied with all necessary fittings, saving considerable installation time. Fixed hose connector Ø 38 mm for filling and fixed hose connector Ø 16 mm for venting. Rotating hose connector Ø 13 mm with pick-up hose for water suction.

A center point for an SAE flange pressure gauge transmitter is integrated into the casting, along with five blind bolt holes.

Features :

Tank volume (liter): 40.

Ø Filling (mm): 38.

Ø Suction (mm): 16.

Ø Vent (mm): 13.

  • VETUS : WTANK40C
  • VDM : VETWTANK40C
