Ref. DAM : DM_VE_BOW9524D

BOW THRUSTER, 95 KGF, 24 V, NOZZLE DIAMETER 185 MM

3618 €3,618.00 VAT included
€3,015.00 VAT excluded
On demand
BOW THRUSTER, 95 KGF, 24 V, NOZZLE DIAMETER 185 MM
BOW THRUSTER, 95 KGF, 24 V, NOZZLE DIAMETER 185 MM
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
BOW THRUSTER, 95 KGF, 24 V, NOZZLE DIAMETER 185 MM
BOW THRUSTER, 95 KGF, 24 V, NOZZLE DIAMETER 185 MM
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
3618 €3,618.00 VAT included
€3,015.00 VAT excluded

These original VETUS DC bow and stern thrusters are the basis for a wide range of DC electric thrusters such as VETUS Standard DC Thrusters, Extended Range Thrusters, Explosion-Proof Thrusters and Retractable Thrusters. Developed and perfected with 40 years of hard work, installed on boats all over the world and operating in all possible conditions.

The advantages of VETUS bow thrusters are endless, but below we highlight the most important features:

Minimal noise pollution due to the unique six-blade propeller design, bevel gears and flexible coupling

High quality control panel made of aluminum and interchangeable with older panels

Smooth flow thanks to a profiled base

Built-in thermal switch to prevent overheating

Eliminates corrosion and reduces weight thanks to synthetic propellers

High performance, efficient and reliable carbon brush electric DC motor

Easy installation and clear instructions

Simple and intuitive use

Features :

Thrust*: 105kgf

Spark protection available: yes

Power (kw-hp): 5.7kw / 8hp

DC motor: 24V

Recommended boat length (ft - m): 36' to 55' / 11.50m to 17m

Nozzle diameter (mm-inch): 185mm / 7.3"

Weight without tunnel: 26 kg

For DC system Volt: 24V

Main battery switch: BATSW250 - BPMAIN24

Main fuse: 200

CCE battery in EN value (min/max): 533/1067

* All VETUS DC thrusters are rated at a battery voltage of 10.5 or 21 VDC. This takes into account the voltage drop caused by the thruster.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

These original VETUS DC bow and stern thrusters are the basis for a wide range of DC electric thrusters such as VETUS Standard DC Thrusters, Extended Range Thrusters, Explosion-Proof Thrusters and Retractable Thrusters. Developed and perfected with 40 years of hard work, installed on boats all over the world and operating in all possible conditions.

The advantages of VETUS bow thrusters are endless, but below we highlight the most important features:

Minimal noise pollution due to the unique six-blade propeller design, bevel gears and flexible coupling

High quality control panel made of aluminum and interchangeable with older panels

Smooth flow thanks to a profiled base

Built-in thermal switch to prevent overheating

Eliminates corrosion and reduces weight thanks to synthetic propellers

High performance, efficient and reliable carbon brush electric DC motor

Easy installation and clear instructions

Simple and intuitive use

Features :

Thrust*: 105kgf

Spark protection available: yes

Power (kw-hp): 5.7kw / 8hp

DC motor: 24V

Recommended boat length (ft - m): 36' to 55' / 11.50m to 17m

Nozzle diameter (mm-inch): 185mm / 7.3"

Weight without tunnel: 26 kg

For DC system Volt: 24V

Main battery switch: BATSW250 - BPMAIN24

Main fuse: 200

CCE battery in EN value (min/max): 533/1067

* All VETUS DC thrusters are rated at a battery voltage of 10.5 or 21 VDC. This takes into account the voltage drop caused by the thruster.

  • VETUS : BOW9524D
  • VDM : VETBOW9524D
