Splash-stop anti-overflow system

The splash-stop is connected directly below the filler cap (1) to ensure that excess fuel or foam cannot flood the deck, foul it or pollute the water.

For installation outside the engine compartment.

Type FS

It has a tank with a capacity of approximately 2 L.

Excess fuel returns to the tank via connection (2).

This connection serves as a vent for the tank. The external breather line must be installed as shown (3). The splash-stop is supplied with fittings for a 51 mm diameter filler pipe.

Model FS5125

Dimensions: L x W x H (mm): Width: 250 x Depth: 120 x Height: 215 mm

Pipe diameter: 51 mm

Event: 25 mm

Deck filler diameter: 51 mm

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Splash-stop anti-overflow system

The splash-stop is connected directly below the filler cap (1) to ensure that excess fuel or foam cannot flood the deck, foul it or pollute the water.

For installation outside the engine compartment.

Type FS

It has a tank with a capacity of approximately 2 L.

Excess fuel returns to the tank via connection (2).

This connection serves as a vent for the tank. The external breather line must be installed as shown (3). The splash-stop is supplied with fittings for a 51 mm diameter filler pipe.

Model FS5125

Dimensions: L x W x H (mm): Width: 250 x Depth: 120 x Height: 215 mm

Pipe diameter: 51 mm

Event: 25 mm

Deck filler diameter: 51 mm

  • VETUS : FS5125
  • VDM : VETFS5125
