Ref. DAM : DM_V _648130

S3 0-190 OHM 300MM FUEL GAUGE

0 €0.00 VAT included
€0.00 VAT excluded
On demand
S3 0-190 OHM 300MM FUEL GAUGE
zoom_in

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
0 €0.00 VAT included
€0.00 VAT excluded

S3 gauges are offered in fixed dimensions measured from the top of the thread. The free distance between the bottom of the tank and the bottom of the gauge increases the reserve volume.

30cm electric cable, 2 wires 0.75 mm².

Electrical resistance 0 to 180 Ohms (European).

Height of gauge head mounted: 21 mm.

Operating temperature: -40°C to +70°C.

Power supply: 12/24 V.

Drilling: BSP R 1-1/4''.

Sensor head outer diameter: 54 mm.

For mounting with 5-hole flange, use reference 648310.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

S3 gauges are offered in fixed dimensions measured from the top of the thread. The free distance between the bottom of the tank and the bottom of the gauge increases the reserve volume.

30cm electric cable, 2 wires 0.75 mm².

Electrical resistance 0 to 180 Ohms (European).

Height of gauge head mounted: 21 mm.

Operating temperature: -40°C to +70°C.

Power supply: 12/24 V.

Drilling: BSP R 1-1/4''.

Sensor head outer diameter: 54 mm.

For mounting with 5-hole flange, use reference 648310.

  • VDM : 648130
  • OSCULATTI : 27.171.30
  • OSCULATTI : 2717130
