Ref. DAM : DM_VE_ASD38V

ANTI-SIPHON ELBOW TYPE ASD 38 MM WITH VALVE

126 €126.00 VAT included
€105.00 VAT excluded
On demand
ANTI-SIPHON ELBOW TYPE ASD 38 MM WITH VALVE
ANTI-SIPHON ELBOW TYPE ASD 38 MM WITH VALVE
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
ANTI-SIPHON ELBOW TYPE ASD 38 MM WITH VALVE
ANTI-SIPHON ELBOW TYPE ASD 38 MM WITH VALVE
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
126 €126.00 VAT included
€105.00 VAT excluded

Anti-siphon elbow with valve and hose. With 4m of 8 x 14mm ventilation hose, suitable for 38mm pipes. Ideal for toilets or holding tanks installed below the waterline.

Interchangeable with AIRVENT type thanks to the same fixing hole centers.

The air bleed fitting rotates 360°. (Includes 2m hose and skin fittings)

A 38 mm diameter flexible hose can be connected directly to the elbow connections. Mount each hose connection with a stainless steel clamp.

Size :

Length (mm): 129.

Width (mm): 48.

Height (mm): 107.

Pipe connection diameter (mm): 38.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Anti-siphon elbow with valve and hose. With 4m of 8 x 14mm ventilation hose, suitable for 38mm pipes. Ideal for toilets or holding tanks installed below the waterline.

Interchangeable with AIRVENT type thanks to the same fixing hole centers.

The air bleed fitting rotates 360°. (Includes 2m hose and skin fittings)

A 38 mm diameter flexible hose can be connected directly to the elbow connections. Mount each hose connection with a stainless steel clamp.

Size :

Length (mm): 129.

Width (mm): 48.

Height (mm): 107.

Pipe connection diameter (mm): 38.

  • VETUS : ASD38V
  • VDM : VETASD38V
