Ref. DAM : DM_VE_WPANEL

12/24V CONTROL UNIT, FOR UP TO 5 SWEEPER ARMS, INCLUDING BOARD

634.5 €634.50 VAT included
€528.75 VAT excluded
On demand
12/24V CONTROL UNIT, FOR UP TO 5 SWEEPER ARMS, INCLUDING BOARD
zoom_in

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
634.5 €634.50 VAT included
€528.75 VAT excluded

The WPANEL panel can control up to 5 wiper motors to operate synchronously at high or low speed.

Each wiper motor is switched individually, so you can choose which wipers are operational.

They also have a combination switch for washing/wiping screen activation, speed selection and wiping interval delay. The wiper motors to be connected must have a 2-speed motor and an automatic parking position.

Up to three MARBO rain sensors (1 x MARBO and 2 x MARBO2) can be connected to the control unit. The rain sensor function can be activated by the

control panel provided and can activate all connected wipers simultaneously.

The WPANEL type comes with:

• 1 control box with electronic overload protection (DIN rail mounting).

• 5 wiper motor switches.

• 1 combination switch for washing/wiping and speed selection.

• 1 mounting plate with space for 6 switches and 2 plates.

Features :

• Available for 12 or 24 volt DC power supply.

• Standby power consumption approx. 10 mA.

• Maximum power per wiper motor 120 W.

• Internal fuses 10 A per wiper motor, 5 A for screen wash pump or solenoid valve.

• Dimensions control panel 49 x 24 x 37.5 mm, control unit 159 x 90 x 58 mm.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

The WPANEL panel can control up to 5 wiper motors to operate synchronously at high or low speed.

Each wiper motor is switched individually, so you can choose which wipers are operational.

They also have a combination switch for washing/wiping screen activation, speed selection and wiping interval delay. The wiper motors to be connected must have a 2-speed motor and an automatic parking position.

Up to three MARBO rain sensors (1 x MARBO and 2 x MARBO2) can be connected to the control unit. The rain sensor function can be activated by the

control panel provided and can activate all connected wipers simultaneously.

The WPANEL type comes with:

• 1 control box with electronic overload protection (DIN rail mounting).

• 5 wiper motor switches.

• 1 combination switch for washing/wiping and speed selection.

• 1 mounting plate with space for 6 switches and 2 plates.

Features :

• Available for 12 or 24 volt DC power supply.

• Standby power consumption approx. 10 mA.

• Maximum power per wiper motor 120 W.

• Internal fuses 10 A per wiper motor, 5 A for screen wash pump or solenoid valve.

• Dimensions control panel 49 x 24 x 37.5 mm, control unit 159 x 90 x 58 mm.

  • VETUS : WPANEL
  • VDM : VETWPANEL
