Ref. DAM : DM_VE_MAA3520L

HEAVY DUTY OCEAN ALUMINUM HATCH 347 X 202 MM

315 €315.00 VAT included
€262.50 VAT excluded
On demand
HEAVY DUTY OCEAN ALUMINUM HATCH 347 X 202 MM
HEAVY DUTY OCEAN ALUMINUM HATCH 347 X 202 MM
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
HEAVY DUTY OCEAN ALUMINUM HATCH 347 X 202 MM
HEAVY DUTY OCEAN ALUMINUM HATCH 347 X 202 MM
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
315 €315.00 VAT included
€262.50 VAT excluded

Ventilation hatch - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke” colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 399 x 254.

Cut-out dimensions C x D (in mm): 347 x 202.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Ventilation hatch - Type MAGNUS (AI)

MAGNUS hatches have a satin anodized profile frame with 10mm thick “dark smoke” colored acrylic and are designed for offshore use, Design Category A, Zone I.

These hatches can be opened from the inside or outside and can remain open at any angle up to 180º with almost no obstruction in the opening.

They have a ventilation position and can be locked completely tightly.

The application on habitable multihulls as a means of evacuation in an inverted position is subject to European legislation.

Warning :

VETUS strongly advises against installing a MAGNUS AI panel below deck level in areas where (temporary) immersion may occur. When installing a panel below deck, always pay special attention to the base area, as hull flexing will compromise the watertightness of any panel.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 399 x 254.

Cut-out dimensions C x D (in mm): 347 x 202.

  • VETUS : MAA3520L
  • VDM : VETMAA3520L
