Ref. DAM : DM_VE_LIB4155L

LIBERO TYPE 41 SURVIVAL HATCH, RADIUS 55 MM (CUT OUT SIZE 410 X 410 MM)

583.5 €583.50 VAT included
€486.25 VAT excluded
On demand
LIBERO TYPE 41 SURVIVAL HATCH, RADIUS 55 MM (CUT OUT SIZE 410 X 410 MM)
LIBERO TYPE 41 SURVIVAL HATCH, RADIUS 55 MM (CUT OUT SIZE 410 X 410 MM)
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
LIBERO TYPE 41 SURVIVAL HATCH, RADIUS 55 MM (CUT OUT SIZE 410 X 410 MM)
LIBERO TYPE 41 SURVIVAL HATCH, RADIUS 55 MM (CUT OUT SIZE 410 X 410 MM)
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
583.5 €583.50 VAT included
€486.25 VAT excluded

Escape hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 470 x 470.

Cut-out dimensions C x D (in mm): 410 x 410.

Cutting radius R (in mm): 55.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Escape hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 2.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

External dimensions A x B (in mm): 470 x 470.

Cut-out dimensions C x D (in mm): 410 x 410.

Cutting radius R (in mm): 55.

  • VETUS : LIB4155L
  • VDM : VETLIB4155L
