Ref. DAM : DM_VE_LIB2032L

LIBERO TYPE 20 VENTILATION COVER, RADIUS 32 MM (CUT OUT SIZE 200 X 200 MM)

268.5 €268.50 VAT included
€223.75 VAT excluded
On demand
LIBERO TYPE 20 VENTILATION COVER, RADIUS 32 MM (CUT OUT SIZE 200 X 200 MM)
LIBERO TYPE 20 VENTILATION COVER, RADIUS 32 MM (CUT OUT SIZE 200 X 200 MM)
Previous keyboard_arrow_left
Next keyboard_arrow_right
zoom_in
LIBERO TYPE 20 VENTILATION COVER, RADIUS 32 MM (CUT OUT SIZE 200 X 200 MM)
LIBERO TYPE 20 VENTILATION COVER, RADIUS 32 MM (CUT OUT SIZE 200 X 200 MM)
Previous
Next

Pièce non en stock.

Demandez le délai de réapprovisionnement et le tarif en cliquant sur le bouton « Ask for a quote ».

Un conseiller traitera votre demande dans la journée.

On demand
268.5 €268.50 VAT included
€223.75 VAT excluded

Ventilation hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 1.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

Mosquito net type: HCM2020.

External dimensions A x B (in mm): 260 x 260.

Cut-out dimensions C x D (in mm): 200 x 200.

Cutting radius R (in mm): 32.

Read the detailed description
Quantity
Vérifier la compatibilité Identifiez votre moteur pour vérifier la compatibilité de ce produit Vérifier la compatibilité

Ventilation hatches - Type LIBERO (AII).

These hatches feature a hand polished and anodized aluminum frame with a 32 or 55mm corner radius and a 10mm dark colored acrylic cover.

The deck hatches and escape hatches come with adjustment devices to hold the cover open at almost any angle up to 90º.

A special friction hinge allows the ventilation hatches to stay open at any angle up to 180º.

The LIBERO type is suitable for design category A, zone II.

Features :

Number of handles: 1.

Shape: Square.

Panel opening: Framed.

Friction hinges: Yes.

Mosquito net type: HCM2020.

External dimensions A x B (in mm): 260 x 260.

Cut-out dimensions C x D (in mm): 200 x 200.

Cutting radius R (in mm): 32.

  • VETUS : LIB2032L
  • VDM : VETLIB2032L
